Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare

Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare

high brightness display

daylight readable lcd monitor

Place of Origin:

Shenzhen,China

Brand Name:

Sihovision

Certification:

CE,FCC, RoHS

Model Number:

SL07

Contact Us
Request A Quote
Product Details
Product Name:
7 Inch Capacitive Touch Screens
Products Status:
Stock
Resolution:
1024*600
Screen Size:
7"
Interface:
VGA,HDMI
Brightness:
1000+ Nits
Touchscreen Type:
Project Capacitive Touch (10 Points )
IP Grade:
Front Panel IP65 Waterproof
Viewing Angle:
85°/85°/80°/80° (R/L/U/D)
Material:
Aluminum Alloy Frame
Power Supply:
DC 12V(AC 100-240V 50/60Hz)
Widescreen:
No
Panel Type:
TFT
Color:
Black
Application:
Embedded/desktop/wall Mount
Warranty:
1 Years
Payment & Shipping Terms
Minimum Order Quantity
1 Piece
Price
Negotiable
Payment Terms
L/C, T/T, Western Union, Paypal, MoneyGram
Product Description

Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare



Key Features:



1. Robust and durable aluminium alloy bezel+ High strength cold rolled steel back enclosure, dustproof and shockproof.
2. Industrial LCD panel, wide viewing angle, high nits, true color.
3. Multi-points PCAP touch panel , high sensitive and fast-response.
4. High performance mainboard, 7x24 continuous operation.
5. Adopt HDMI 1.4 Digital decoding scheme, strong compatibility.
6.1000 nits high brightness,sunlight readable.
7.Front panel IP65 waterproof.



Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare 0

Wide working temperature

Wide Temperature Range: operating: -20 to 70°C, storage: -30 to 80°C.

Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare 1

Touch with gloves

Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare 2

EETI waterproof solution

Touch function can work well with drop water on the screen.

Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare 3

With Anti glare function

Covered with 2mm Anti glare glass, sunlight readable.

Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare 4



Specification

Model:SL07
LCD panel
Panel size 7"
Resolution 1024*600
Aspect ratio 16:9
Support Color 16.7M colors
Brightness (cd/m²) 1000 nits,sunlight readable
Contrast ratio 400:1
View angle 85°/85°/80°/80° (R/L/U/D)
Touch panel
Touchscreen Type Project Capacitive Touch (10 points )
Surface Hardness 7H
Luminousness 90%
Touch Interface USB
Touch response time 2ms
Working Life >50 million times
Touch options (4 wires resistive touch, IR touch optional)
Singal Ports
VGA 1×VGA
HDMI 1×HDMI
DVI optional
AV optional
Audio in/out optional
OSD
OSD control

Brightness, contrast ratio, auto adjustment, H/V position, language select etc.

Support languages

English, French, Spanish, Portuguese, Italian, German, Russian, Japanese,

Chinese etc.

Support OS Windows XP , Windwows /7/8/10 , Linux, Mac OS X, Android ect.
Power Supply
External Power Supply AC 100 - 240V
Working voltage DC 12V
Power consumption ≤10W
Enclosure
Appearance Flat panel , demountable open frame for mounting
Material aluminium alloy bezel+High strength cold rolled steel back case
Color Black, white, Silver , color can be customized
VESA mounting 75×75mm
IP Grade front panel IP65 waterproof
Operating Environment
Temperature Range operating: -10 to 60°C, storage :-20 to 80°C
Relative humidity operating: 10% to 90% , storage :5% to 90%
Packing Details
Net weight 1.85kg
Gross weight 2.5kg
Product Dimension 19.1×12.8×3.4 cm
Packing size 37×28×10 cm
Accessories Power adapter, HDMI /VGAcable, USB touch cable
Other
Mounting Embedded screws
wall mounting brackets (optional)
desk stand holder (optional)
Warranty 1 year warranty
Certificates CE, FCC, RoHS





Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare 5



Accessories:

Power cable, Power adapter, Touch cable, Video cable, Screws

Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare 6

Application:

Gas station
Nautical navigation
Access control system
Water distribution system
Motorway payment system
EV-charging infrastructure

Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare 7



Products line:

Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare 8

Certifications

Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare 9



OEM & ODM



Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare 10



About Shinho Electronic
Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare 11
