Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare

Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare
Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare

Large Image :  Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare

Product Details:
Place of Origin: Shenzhen,China
Brand Name: Sihovision
Certification: CE,FCC, RoHS
Model Number: SL07
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: Negotiable
Packaging Details: 37×28×10 cm 2.5kg
Delivery Time: 5-8 working days
Payment Terms: L/C, T/T, Western Union, Paypal, MoneyGram
Supply Ability: 5000 Pieces Per Month
Detailed Product Description
Product Name: 7 Inch Capacitive Touch Screens Products Status: Stock
Resolution: 1024*600 Screen Size: 7"
Interface: VGA,HDMI Brightness: 1000+ Nits
Touchscreen Type: Project Capacitive Touch (10 Points ) IP Grade: Front Panel IP65 Waterproof
Viewing Angle: 85°/85°/80°/80° (R/L/U/D) Material: Aluminum Alloy Frame
Power Supply: DC 12V(AC 100-240V 50/60Hz) Widescreen: No
Panel Type: TFT Color: Black
Application: Embedded/desktop/wall Mount Warranty: 1 Years
High Light:

high brightness display

,

daylight readable lcd monitor

Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare



Key Features:



1. Robust and durable aluminium alloy bezel+ High strength cold rolled steel back enclosure, dustproof and shockproof.
2. Industrial LCD panel, wide viewing angle, high nits, true color.
3. Multi-points PCAP touch panel , high sensitive and fast-response.
4. High performance mainboard, 7x24 continuous operation.
5. Adopt HDMI 1.4 Digital decoding scheme, strong compatibility.
6.1000 nits high brightness,sunlight readable.
7.Front panel IP65 waterproof.



Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare 0

Wide working temperature

Wide Temperature Range: operating: -20 to 70°C, storage: -30 to 80°C.

Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare 1

Touch with gloves

Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare 2

EETI waterproof solution

Touch function can work well with drop water on the screen.

Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare 3

With Anti glare function

Covered with 2mm Anti glare glass, sunlight readable.

Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare 4



Specification

Model:SL07
LCD panel
Panel size 7"
Resolution 1024*600
Aspect ratio 16:9
Support Color 16.7M colors
Brightness (cd/m²) 1000 nits,sunlight readable
Contrast ratio 400:1
View angle 85°/85°/80°/80° (R/L/U/D)
Touch panel
Touchscreen Type Project Capacitive Touch (10 points )
Surface Hardness 7H
Luminousness 90%
Touch Interface USB
Touch response time 2ms
Working Life >50 million times
Touch options (4 wires resistive touch, IR touch optional)
Singal Ports
VGA 1×VGA
HDMI 1×HDMI
DVI optional
AV optional
Audio in/out optional
OSD
OSD control

Brightness, contrast ratio, auto adjustment, H/V position, language select etc.

Support languages

English, French, Spanish, Portuguese, Italian, German, Russian, Japanese,

Chinese etc.

Support OS Windows XP , Windwows /7/8/10 , Linux, Mac OS X, Android ect.
Power Supply
External Power Supply AC 100 - 240V
Working voltage DC 12V
Power consumption ≤10W
Enclosure
Appearance Flat panel , demountable open frame for mounting
Material aluminium alloy bezel+High strength cold rolled steel back case
Color Black, white, Silver , color can be customized
VESA mounting 75×75mm
IP Grade front panel IP65 waterproof
Operating Environment
Temperature Range operating: -10 to 60°C, storage :-20 to 80°C
Relative humidity operating: 10% to 90% , storage :5% to 90%
Packing Details
Net weight 1.85kg
Gross weight 2.5kg
Product Dimension 19.1×12.8×3.4 cm
Packing size 37×28×10 cm
Accessories Power adapter, HDMI /VGAcable, USB touch cable
Other
Mounting Embedded screws
wall mounting brackets (optional)
desk stand holder (optional)
Warranty 1 year warranty
Certificates CE, FCC, RoHS





Front IP65 Waterproof High Brightness 1000 nits industrial displays with Anti glare 5



Accessories:

Power cable, Power adapter, Touch cable, Video cable, Screws
