Place of Origin:
China
Brand Name:
Sihovision
Certification:
CE,FCC,RoHS
Model Number:
SL32
Vertical display white 32 inch infrared touchscreen monitor with VGA HDMI DVI
Features:
1. Light weight, use 1.2mm thick high quality metal case, inner structure with reinforcement design .
2. Industrial LCD panel, IPS full viewing angle, high nits, true color.
3. Multipoint infrared touch panel with waterproof and work well in direct sunlight.
4. Auto-adjust the brightness during the night, power saving.
5. High performance mainboard, 7x24 continuous operation.
6. Adopt HDMI 1.4 Digital decoding scheme, strong compatibility
Specification
| Model:SL32 | |
| LCD panel | |
| Panel size | 32" |
| Resolution | 1920*1080 |
| Aspect ratio | 16:9 |
| Support Color | 16.7M colors |
| Brightness | 450cd/m² (1000cd/m² optional ) |
| Contrast ratio | 1400:1 |
| View angle | 89°/89°/89°/89° (R/L/U/D) |
| Touch panel | |
| Touch panel type | 2-points infrared touch panel ( 4-points , 6-points optional ) |
| Tempered glass | Thickness: 3mm, customizable |
| Mohs hardness: 6.5 | |
| Luminousness: up to 95% | |
| Interface | USB (RS232 optional) |
| Touch response time | 5ms |
| Working Life | >50 million times |
| Touch options | PCAP touch optional |
| Signal Ports | |
| HDMI | 1×HDMI |
| VGA | 1×VGA |
| DVI | 1×DVI |
| Audio in/out | 1×Audio in/out |
| AV | optional |
| OSD | |
| OSD control | Brightness, contrast ratio, auto adjustment, H/V position, language select etc. |
| Support languages | English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese etc. |
| Support OS | Windows XP , Windwows /7/8/10 , Linux, Mac OS X, Android ect. |
| Power Supply | |
| External Power Supply | AC 100 - 240V |
| Working voltage | DC 24V |
| Power consumption | ≤50W |
| Enclosure | |
| Material | High strength cold rolled steel |
| Color | Black, white, Silver , color can be customized |
| VESA mounting | 200×200 mm |
| Operating Environment | |
| Temperature Range | operating: -10 to 60°C, storage :-20 to 80°C |
| Relative humidity | operating: 10% to 90% , storage :5% to 90% |
| Packing Details | |
| Net weight | 18kg |
| Gross weight | 20kg |
| Product Dimension | 74.5×44×5.5cm |
| Packing size | 99×64×18cm |
| Accessories | Power adapter,HDMI/USB cables |
| Other | |
| Mounting (options) | 1) provide wall brackets for wall-mounting, VESA 200×200mm |
| 2) provide stable metal holder to support the monitor | |
| Warranty | 1 year warranty |
| Certificates | CE,FCC,RoHS |
Drawing
Application:
petrol station ordering,semi outdoor advertising,self service kiosk...
