7 inch 1000 Nits Industrial Monitor Outdoor HDMI LCD Touch Screen
Features
This LCD monitor featuring 4 wire resistive touch screen is an economical industrial monitor choice. It comes with 7 inch industrial-grade LCD panel. Resolution is 1024*600. With 1000 nits luminance and FULL IP65 waterproof grade, you don't need to have any concern to use it outdoor. What's more, it has waterproof speaker on the back case, and buttons on the bezel to adjust brightness.
Advantages
1. Robust and durable Aluminum alloy front cover and metal rear cover
2. Industrial A LCD panel, high brightness 1000nits, sunlight readable
3. FULL IP65 water resistant
4. Adopt high precision industrial 4 wires resistive touch screen, high precision, durable, anti-interference.
5. Support wide voltage: 12-24V DC input.
6. With waterproof speaker on the back case.
7. With button on the bezel, to adjust the brightness.
Applications
Restaurant
Self-service kiosk
Gas station
Payment terminal machine
Vehicle
Bus stop
Specification
| Model:SL07W | |
| LCD panel | |
| Panel size | 7" |
| Resolution | 1024*600 |
| Aspect ratio | 16:9 |
| Support Color | 16.7M colors |
| Brightness (cd/m²) | 1000 nits,sunlight readable |
| Contrast ratio | 400:1 |
| View angle | 80°/80°/80°/80° (R/L/U/D) |
| Touch panel | |
| Touchscreen Type | 4 wire resistive touch |
| Touch Interface | USB (RS232 optional) |
| Touch response time | <8ms |
| Luminousness | 75-85% |
| Surface Hardness | 3H |
| Working Life | >35 million times |
| Touch options | (PCAP touch optional) |
| Singal Ports | |
| VGA | optional |
| HDMI | 1×HDMI |
| DVI | optional |
| AV | optional |
| Audio in/out | optional |
| OSD | |
| OSD control | Brightness, contrast ratio, auto adjustment, H/V position, language select etc. |
| Support languages | English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese etc. |
| Support OS | Windows XP , Windwows /7/8/10 , Linux, Mac OS X, Android ect. |
| Power Supply | |
| External Power Supply | AC 100 - 240V |
| Working voltage | DC 12V-24V wide voltage |
| Power consumption | 10W |
| Enclosure | |
| Material | Aluminum alloy bezel+High strength cold rolled steel back case |
| Color | Black, white, Silver , color can be customized |
| VESA mounting | 75×75mm |
| IP-grade | IP65 |
| Operating Environment | |
| Temperature Range | operating: -10 to 60°C, storage :-20 to 80°C |
| Relative humidity | operating: 10% to 90% , storage :5% to 90% |
| Packing Details | |
| Net weight | 1.3kg |
| Gross weight | 2kg |
| Product Dimension | 20×12×3.5 cm |
| Packing size | 33.0×21.6×8.7 cm |
| Accessories | Power adapter, touch pen , touch driver |
| Other | |
| Mounting (options) | 1) provide wall brackets for wall-mounting, VESA 75×75mm |
| 2) provide stable metal holder to support the monitor | |
| Warranty | 1 year |
