10.4 Inch 1000 Nits Resistive Touch Monitor 1024*768 With Sealed I/O Cable Set

Place of Origin China(Mainland)
Brand Name Sihovision
Certification CE, FCC, RoHS
Model Number SL104W
Minimum Order Quantity 1 piece
Price Negotiable
Packaging Details 64×42×19 cm 6.5kg
Delivery Time 5-7 working days for sample, 10-15 working days for bulk
Payment Terms T/T, Western Union, MoneyGram, Paypal
Supply Ability 5000pcs/month
Product Details
Product Name 10.4 Inch Full IP67 Resistive Touch Monitor Products Status Stock
Material Aluminium Alloy Resolution 1024*768
Brightness 1000+ Cd/m2 Interface VGA,USB,HDMI
Response Time 2ms View Angle 80°/80°/80°/80° (R/L/U/D)
Type Touch Screen Monitor Touch Type 5-Wire Resistive Touch
IP Grade IP67 Color Black
Power Supply DC 12V(AC 100-240V 50/60Hz) Application Desktop,monitor,Embedded,banana Pi,VESA Mount
Warranty 12months
High Light

touch screen display monitor

,

resistive touch screen monitor

Leave a Message
Product Description

10.4 inch 1000 nits sunlight readable Industrial resistive touch monitor with sealed I/O cable set



Features


1. Robust and durable, all-metal enclosure, sealing design, full IP67 waterproof, Sealed I/O with cable set included.
2. 10.4'' Industrial LCD panel, high brightness 1000 nits, sunlight readable.
3. Adopt high precision industrial 5 wire resistive touch screen. stable, durable, anti-interference.
4. Wide Temperature Range: operating: -20 to 70°C, storage: -30 to 80°C.
5. High performance mainboard, 7x24 continuous operation.

Specification



Model:SL104W
LCD panel
Panel size 10.4"
Resolution 1024*768
Aspect ratio 4:3
Support Color 16.7M colors
Brightness (cd/m²) 1000 nits, sunlight readable
Contrast ratio 1000:1
View angle 80°/80°/80°/80° (R/L/U/D)
Touch panel
Touchscreen Type 5 wire resistive touch
Touch Interface USB (RS232 optional)
Touch response time <8ms
Luminousness 75-85%
Surface Hardness 3H
Working Life >35 million times
Touch options ( PCAP touch optional)
Singal Ports
VGA 1xDVI
HDMI optional
VGA optional
Audio in/out optional
OSD
OSD control Brightness, contrast ratio, auto adjustment, H/V position, language select etc.
Support languages English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese etc.
Support OS Windows XP, Windwows /7/8/10, Linux, Mac OS X, Android, ect.
Power Supply
External Power Supply AC 100-240V
Working voltage DC 12V
Power consumption 25 W
Enclosure
Material aluminium alloy front bezel + High strength cold rolled steel back case
Color Black, white, Silver, color can be customized
VESA mounting 75x75mm / 100x100 mm
IP-grade Full IP67 waterproof
Operating Environment
Temperature Range operating: -20 to 70°C, storage: -30 to 80°C
Relative humidity operating: 10% to 90%, storage: 5% to 90%
Packing Details
Net weight 3kg
Gross weight 4kg
Product Dimension 28×21×5.48cm
Packing size 35x30x15 cm
Accessories Power adapter, Waterproof DVI/USB cable, Waterproof Power cord
Other
Mounting (options) 1) wall brackets for wall-mounting, VESA 100×100 mm
2) stable metal holder to support the monitor
Warranty 1 year warranty





Drawing
10.4 Inch 1000 Nits Resistive Touch Monitor 1024*768 With Sealed I/O Cable Set 0



Package

10.4 Inch 1000 Nits Resistive Touch Monitor 1024*768 With Sealed I/O Cable Set 1



Certifications

10.4 Inch 1000 Nits Resistive Touch Monitor 1024*768 With Sealed I/O Cable Set 2



OEM & ODM



10.4 Inch 1000 Nits Resistive Touch Monitor 1024*768 With Sealed I/O Cable Set 3



About Shinho Electronic
10.4 Inch 1000 Nits Resistive Touch Monitor 1024*768 With Sealed I/O Cable Set 4


Application

10.4 Inch 1000 Nits Resistive Touch Monitor 1024*768 With Sealed I/O Cable Set 5
Smart City
Intelligent Education
Public Transportation
Commercial Terminals
Industrial automation area
Product Stamping and Packaging
