IP65 Waterproof Rugged Industrial Panel Pc Touch Screen 8 Inch Embedded DC 12V

IP65 Waterproof Rugged Industrial Panel Pc Touch Screen 8 Inch Embedded DC 12V

industrial all in one pc touch screen

industrial touch panel computer

Place of Origin:

China(Mainland)

Brand Name:

Sihovision

Certification:

CE, FCC, RoHS

Model Number:

SC08W

Contact Us
Request A Quote
Product Details
Product Name:
8 Inch Full IP65 Waterproof Industrial Pc
Type:
Panel Pc
Products Status:
Stock
Cpu:
N2800
Memory:
2GB/4GB/8GB
Storage:
32G/64G/128G/256G SSD
Resolution:
1024x768
Brightness:
1000+ Cd/m2
Interface:
COM, VGA, USB, HDMI
Response Time:
2ms
View Angle:
80°/80°/80°/80° (R/L/U/D)
Lan:
2x10/100/1000Mbps RJ45 LAN
Wifi:
802.11a/b/g/n
Material:
Aluminium Alloy
Color:
Black
Touch Screen:
4 Wire Resistive Touch
Operating System:
Windows 7/8/10/linux/Ubuntu
Power Supply:
DC 12V(AC 100-240V 50/60Hz)
Warranty:
12months
Payment & Shipping Terms
Minimum Order Quantity
1 piece
Price
Negotiable
Payment Terms
T/T, Western Union, MoneyGram, Paypal
Product Description

8 inch full IP65 waterproof rugged embedded touch screen panel pc for industrial



Features


1. Sturdy and durable aluminum Alloy front bezel + High strength cold rolled steel back case.
2.Industrial LCD panel, wide viewing angle, high nits, true color.
3. Adopt 4 wires resistive touch screen, high precision, durable, anti-interference.
4. High performance motherboard, 7x24 continuous operation.
5. Full sealed and fanless design, full IP65 waterproof , sunlight readable.

Specification



Model:SC08W
PC
CPU Intel® Atom N2800, 1.86GHz, dual core, fanless
Chipset Intel NM10
Memory 2G DDR3, (4G optional)
Hard Drive Capacity 32G SSD
Hard Drive Optional SSD: 64G,128GB,256GB
HDD: 500GB,1TB
Graphics CPU Integrated graphics HD Graphics and support 1080p HD photo quality
Audio Realtek ALC662, High Definition Audio (HD), Line in, Line out
Network Onboard Realtek RTL 8111E Gigabit Ethernet controller
Wireless Network WIFI optional
I/O Interface 3 xCOM RS232, 2 xLAN, 4xUSB, 1xVGA
Operation System Support Windows 7/8/10, Linux, Ubuntu, Debian etc.
LCD panel
Panel size 8"
Resolution 1024x768
Aspect ratio 4:3
Support Color 16.7M colors
Brightness (cd/m²) 1000 nits,sunlight readable
Response time 2ms
Contrast ratio 700:1
View angle 80°/80°/80°/80° (R/L/U/D)
Touch panel
Touchscreen Type 4 wire resistive touch
Surface Hardness 3H
Luminousness 90%
Touch Interface USB
Touch response time 2ms
Working Life >35 million times
Touch options (10 point capacitive touch optional)
Power Supply
External Power Supply AC 100 - 240V
Working voltage 12V (9-36V wide voltage optional)
Power consumption ≤25W
Enclosure
Material Aluminum Alloy front bezel + High strength cold rolled steel back case
Color Black( white, Silver , color can be customized )
VESA mounting 75×75mm
IP-grade IP65
Operating Environment
Temperature Range operating: -10 to 60°C, storage :-20 to 80°C
Relative humidity 5%~95% @ 40° C, non-condensing
Vibration 5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
Packing Details
Net weight 4KG
Gross weight 6KG
Product Dimension 25×19.9×5.1 cm
Packing size 40×35×17 cm
Accessories Power adapter,waterproof VGA/RS232/LAN/USB cable,touch driver,touch pen
Other
Mounting (options) 1) provide wall bracket for wall-mounting, VESA 75×75mm
2) provide stable metal holder to support the monitor
Warranty 1 year warranty







Drawing



IP65 Waterproof Rugged Industrial Panel Pc Touch Screen 8 Inch Embedded DC 12V 0



Package

IP65 Waterproof Rugged Industrial Panel Pc Touch Screen 8 Inch Embedded DC 12V 1



Certifications

IP65 Waterproof Rugged Industrial Panel Pc Touch Screen 8 Inch Embedded DC 12V 2



OEM & ODM



IP65 Waterproof Rugged Industrial Panel Pc Touch Screen 8 Inch Embedded DC 12V 3



About Shinho Electronic
IP65 Waterproof Rugged Industrial Panel Pc Touch Screen 8 Inch Embedded DC 12V 4


Application

IP65 Waterproof Rugged Industrial Panel Pc Touch Screen 8 Inch Embedded DC 12V 5
Smart City
Intelligent Education
Public Transportation
Commercial Terminals
Industrial automation area
Product Stamping and Packaging
