Stainless Steel Waterproof Touch Monitor Anti Fogging Displays Black Powder Coating
Product Details
| Product Name | 215 Inch Stainless Steel Display | Products Status | Stock |
|---|---|---|---|
| Resolution | 1024*768 | Screen Size | 15" |
| Interface | BNC, HDMI | Brightness | 1000 Nits |
| IP Grade | Full IP66 Waterproof | Viewing Angle | 80°/80°/80°/80° (R/L/U/D) |
| Material | Stainless Steel 304 | Power Supply | DC 12V(AC 100-240V 50/60Hz) |
| Widescreen | Yes | Panel Type | TFT |
| Color | Black | Application | Desktop/wall Mount |
| Warranty | 1 Years | ||
| High Light | marine computer monitors,waterproof hdmi monitor |
||
Product Description
Anti-fogging displays Black Powder coating Stainless Steel Full IP66 Waterproof Monitor
Key Features:
1. IP66 sealed stainless steel enclosure, Sealed I/O cables included.
2. Black Powder coated Housing with front OSD buttons.
3. Industrial LCD panel, wide viewing angle, true color.
4. 1000 nits high brightness, sunlight readable.
5. Covered with 3mm AF glass, anti-fogging, anti-fingerprint.
6. Interfaces: Video (BNC) & HDMI & DC12V (Power)
7. High performance motherboard, 7x24 continuous operation.
Wide working temperature
Wide Temperature Range: operating: -20 to 70°C, storage: -30 to 80°C.
Full IP66 waterproof
Specification
| Model: SL215-WSIP66 | |
| LCD panel | |
| Panel size | 21.5" |
| Resolution | 1920*1080 |
| Aspect ratio | 16:9 |
| Support Color | 16.7M colors |
| Brightness (cd/m²) | 1000 cd/m², sunlight readable |
| Contrast ratio | 1000:1 |
| View angle | 80°/80°/80°/80° (R/L/U/D) |
| Customization | Covered 3mm Anti-fogging glass |
| Signal Ports | |
| HDMI | 1x HDMI |
| BNC | 1x BNC |
| VGA | optional |
| Audio in/out | optional |
| OSD in the front bezel | |
| OSD control |
Brightness, contrast ratio, auto adjustment, H/V position, language select, etc. |
| Support languages |
English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese, etc. |
| Support OS | Windows XP, Windows /7/8/10, Linux, Mac OS X, Android, ect. |
| Power Supply | |
| External Power Supply | AC 100 - 240V, 50-60Hz |
| Working voltage | DC 12V |
| Power consumption | ≤35W |
| Enclosure | |
| Material | Stainless steel 304 |
| Color | Black |
| VESA mounting | 100x100mm |
| IP grade | Full IP66 |
| Operating Environment | |
| Temperature Range | operating: -10 to 60°C, storage: -20 to 70°C |
| Relative humidity | operating: 10% to 80%, storage: 5% to 90% |
| Packing Details | |
| Net weight | 7KG |
| Gross weight | 9 KG |
| Product Dimension | 53.16*32.82*5.74cm |
| Packing size | 65x45x19 cm |
| Accessories | IP66 waterproof Power adapter, Power cord, waterproof HDMI and BNC cables |
| Other | |
| Mounting | VESA mounting |
| embedded mounting screws (optional) | |
| desk stand holder (optional) | |
| Warranty | 1 year warranty |
| Certificates | CE, FCC, RoHS |
Accessories:
Power cable, Power adapter, Video cable, Screws
