Sunlight Readable 10.1 Inch RK3288 Industrial Android Tablet
Product Details
| Product Name | 10.1 Inch Industrial Android Tablet Panel Pc | Products Status | Stock |
|---|---|---|---|
| Material | Aluminum Alloy | Cpu | RK3288 |
| Memory | 2GB | Storage | 8GB |
| Resolution | 1280*800 | Brightness | 1000cd/m2 |
| View Angle | 85°/85°/80°/80° (R/L/U/D) | Touch Type | 10 Points Capacitive Touch Or 5-Wire Resistive Touch |
| Type | Panel PC | IP Grade | Front IP65 Waterproof |
| Working Voltage | 12-24V | Warranty | 12months |
| High Light | RK3288 Industrial Android Tablet,10.1 Inch Industrial Android Tablet,Sunlight Readable Rugged Android Tablet |
||
Product Description
Sunlight Readable 10.1 inch RK3288 Processor Android Tablet Panel PC With Light Sensor for Auto Dimming
Features
1. Front bezel aluminum alloy brushed metal craft, seamless design, front panel IP65 waterproof.
2. Industrial LCD panel, full viewing angle, high nits, true color.
3. Adopt multi-points PCAP touch panel, high sensitive and fast-response. Covered with 2mm tempered glass for vandalproof.
4. EETI waterproof solution, touch function can work well with drop water on the screen.
5.1000 nits, sunlight readable, with light sensor for auto dimming.
6. High performance mainboard, 7x24 continuous operation.
7. Wide temperature range: operating: -20 to 70°C, storage: -30 to 80°C.
8. Support wall mounting, embedded mounting, desk stand mounting etc.
Specification
| Model: SC101A | |
| PC | |
| CPU | RK3288 Cortex-A17 quad core,1.8GHz |
| Memory | 2GB DDR3 |
| Storage | 8GB EMMC |
| Decoding Resolution | Support 1080P |
| Operation System | Android 7.1 |
| Play Modes | Support timing, loop and spots etc. play modes |
| Network Support | RJ45, WIFI, 3G, 4G, TD-LTE (optional) |
| Image Format | JPG/BMP/GIF/TIFF/PNG |
| Video Format | RMVB, FLV, MPEG1/2/4, AVI, WMV, MOV, MP4, TS, etc. |
| Audio Format | MP3, WMA, AAC, etc. |
| RTC Real Time Clock | YES |
| I/O Interfaces | |
| USB | 2xUSB (up to 5) |
| COM | 1xCOM |
| LAN | 1xRJ45, 10M/100M adaptive ethernet |
| HDMI | 1xHDMI , support 1080p |
| DC | 1xDC |
| Card Slot | 1xSD |
| LCD panel | |
| Panel size | 10.1" |
| Resolution | 1280*800 |
| Aspect ratio | 16:10 |
| Support Color | 16.7M colors |
| Brightness | 1000 cd/m², sunlight readable |
| Brightness control | Light sensor for auto dimming |
| Response time | 30ms |
| Contrast ratio | 800:1 |
| View angle | 85°/85°/80°/80° (R/L/U/D) |
| Touch panel | |
| Touchscreen Type | 10 point capacitive touch |
| Touch response time | <2ms |
| Luminousness | 90% |
| Surface Hardness | 7H |
| Working Life | >50 million times |
| Power Supply | |
| External Power Supply | AC 100 - 240V |
| Working voltage | DC 12V 4A |
| Power consumption | ≤25W |
| Enclosure | |
| Appearance | Flat panel |
| Material | Aluminum alloy |
| Color | Black, Silver |
| VESA mounting | 75x75mm |
| IP grade | Front IP65 waterproof |
| Operating Environment | |
| Temperature Range | operating: -20 to 70°C |
| Storage temperature | -30°C to 80°C |
| Relative humidity | 5-85% (non-condensing) |
| Vibration resistance | 5-19Hz/1.0mm amplitude, 19-200Hz/1.0g acceleration |
| Impact resistance | 10g acceleration, 11ms period |
| Packing Details | |
| Net weight | 3 kg |
| Gross weight | 3.5 kg |
| Product dimension | 29x20.9x4 cm |
| Packing size | 43x38x18 cm |
| Accessories | Power adapter, power cord, Open frame mounting kits, warranty card |
| Other | |
| Customization (optional) | 3G, 4G, Webcam, RFID reader etc. Optional |
| Warranty | 1 year warranty |
Drawing
Application
Smart City
Intelligent Education
Public Transportation
Commercial Terminals
Industrial automation area
Product Stamping and Packaging
