Bluetooth 5.2 Industrial Mini PC 64G DDR4 4266MHz AMD R7 5800U 100W

Bluetooth 5.2 Industrial Mini PC 64G DDR4 4266MHz AMD R7 5800U 100W

Bluetooth 5.2 Industrial Mini PC

64G DDR4 Industrial Mini PC

100W Desktop Mini Pc

Place of Origin:

Shenzhen, China

Brand Name:

Sihovision

Certification:

CE, FCC, RoHS, ISO9001

Model Number:

SMR75000

Contact Us
Request A Quote
Product Details
Name:
Desktop Mini Pc
CPU:
AMD R7 5800U
Memory Capacity:
2*SO-DIMM SLOTS
Storage:
2*M.2 NVMe SSD+2.5 Inch HDD/SSD
Operation System:
Windows, LINUX
Network:
2*RJ45+WiFi 6&Bluetooth 5.2
Power:
AC 100~240V, 100W
Dimension:
149mm*145mm*40mm
Payment & Shipping Terms
Minimum Order Quantity
1 Piece
Price
negotiable
Payment Terms
T/T , Paypl , L/C , D/A , D/P , Western Union , MoneyGram
Product Description

Dual Channel Memory 64G DDR4 4266MHz AMD R7 5800U 2 Lan Ports Mini PC



Processor parameter for referance only


1. 7nm AMD Ryzen 7 5800U 8 cores 16 threads 1.9GHz up to 4.4GHz 16MB cache TDP 15W Radeon™ Graphics 6 Core 2000MHz.

2. 7nm AMD Ryzen 9 5900H 8 cores 16 threads 3.3GHz up to 4.6GHz 16MB cache TDP 35W Radeon™ Graphics 6 Core 2100MHz.
3. 7nm AMD Ryzen 9 5900HX 8 cores 16 threads 3.3GHz up to 4.6GHz 16MB cache TDP 45W Radeon™ Graphics 8 Core 2100MHz.



Feature



- Onboard high-end AMD Ryzen 5000 series 7nm Processor with powerful computing performance.
- Onboard AMD Radeon™ VEGA Graphics with fast graphics processing capabilities for gaming and 3D design.
- Support HDMI2.0, DP1.4 and Type-C for 3x4K@60Hz video display synchronously and a synchronously.
- Support 2*M.2 2280 NVME/PCIE3.0x4/SATA SSD+1*2.5'' SATA HDD/SSD.
- Support 2.5G&1GDual RJ45 Lans+M.2 2230 2.4G/5G Dual band AC(AX) WiFi/BT.
- Onboard a powerful copper fan for heat dissipation, keep the computer stable working 7x24 hours.
- Support TPM2.0, PXE, RTC, Wake on LAN, Auto power on etc.



Full featured Type-C



* USB 3.2 Gen. 2 data transfer at 10 Gbps
* Video output supports 4K 60Hz display
* 15W (5V @ 3A) USB power delivery / fast charging to quickly recharge your phone or power other peripherals, like a small monitor.
* You can power the S500+ by USB-C instead of the AC adapter (requires a 20V 5A USB-C power supply, not included)
-can connect an external video card using an M.2-to-PCIe adapter (not included).


Specification

Model: SMR75000
PC
CPU R7 5800U
Memory 2*SO-DIMM SLOTS
Storage M.2 2280 PCIE/NVMe/SSD + 2.5 inch HDD/SSD
Graphics AMD Radeon Graphics Vega 8
Operation System Windows10/ Windows11/ ubuntu/ Linux
Network Support WiFi 6+Bluetooth 5.2+Gigabit Ethernet port
I/O Interfaces
USB 3.2 2*USB3.2
USB 2.0 4*USB2.0
Audio 1*Audio
Type C 1*Type C
DC 1*DC
LAN 2*RJ45
DP 1*DP
HD-MI 1*HD-MI
Power Supply
External Power Supply AC 100~240V
Power consumption 120W
Enclosure
Material Aluminum alloy
Color Gray
Operating Environment
Working temperature -10°C to 70°C
Storage temperature -30°C to 80°C
Relative humidity 10-90% (npn-condensing)
Packing Details
Weight 2 kg
Product dimension 149mm*145mm*40mm
Other
Warranty 1 year warranty



Pictures

Bluetooth 5.2 Industrial Mini PC 64G DDR4 4266MHz AMD R7 5800U 100W 0

Bluetooth 5.2 Industrial Mini PC 64G DDR4 4266MHz AMD R7 5800U 100W 1Bluetooth 5.2 Industrial Mini PC 64G DDR4 4266MHz AMD R7 5800U 100W 2



FAQ



Q1.What's the warranty?
Re: 1 year warranty. After expired warranty and sent back to our company, we will still try our best to repair for you without repair cost (except change new accessories).



Q2: Are you a factory or a trading company?
Re: We are one of the professional computer manufacturers located in Shenzhen, China.



Q3: What Operating System is installed before delivery?
Re: Our computers support all kinds of main operating systems. Most buyers prefer Windows and Linux. Unactivated Windows 7 for testing is pre-installed.



Q4.: Can you arrange the shipment? Since it's my first time to buy from China
Re: Yes, for small order, DHL/FedEx/TNT/UPS/EMS will be OK. Sea or air freight is also applicable for bulk order according to your requirement.
