10.1" Projective Capacitive Touchscreen Monitor with High Contrast and IP65 Rating

Brand Name: Sihovision
Model Number: SL101W
MOQ: 1 piece
Price: Negotiation
Payment Terms: T/T, Paypal, L/C, D/A, D/P, Western Union, MoneyGram,
Detail Information
Product Description
Detail Information
Place of Origin:
Shenzhen, China
Certification:
CE, FCC, RoHS
Product Name:
Waterproof Touch Monitor
Panel Size:
10 Inch
Resolution:
1280*800
Aspect Ratio:
16:10
Contrast Ratio:
900:1
Luminance:
1000cd/m2
Touch Type:
Capacitive Touch
Signal Ports:
HDMI
IP Grade:
FULL IP65
Application:
Outdoor
Highlight:

High Contrast Projective Capacitive Touchscreen Monitor

,

10.1” Projective Capacitive Touchscreen Monitor

,

IP65 Rating Projective Capacitive Touchscreen Monitor

Product Description

OEM/ODM IP65 10.1" projective capacitive touchscreen monitor



Features

1. Front aluminum alloy bezel with sandblasting+hard anodizing, UV-protection and Anti-discoloration treatment , Full IP65 waterproof and dustproof.
2. Industrial LCD panel, full view angle, 1000nits sunlight readable, OSD diming brightness
3. HDMI, USB, DC in one cable.
4. EETI waterproof solution, the touch function can work well with drop water on the screen.
5.The monitor is built with industrial-grade components, 7x24 continuous operation, wide temperature operation -20 °C ~ 70°C (-4°F ~158°F).
6. The front frame and the rear shell are sealed with waterproof tape, which can be disassembled for inspection and maintenance without affecting the waterproof performance.

Specification

LCD panel
Panel size10.1"
Display active area216.96(W)×135.6(H) mm / 8.542 in × 5.339 in
Resolution1280*800
Aspect ratio16:10
Brightness (cd/m²)1000 nits sunlight readable
Brightness controlOSD
Contrast ratio900:1
View angle85°/85°/85°/85° (R/L/U/D)
Support Color16.7M
BacklightWLED, 50K hours
Touch panel
Touchscreen TypeCapacitive touch
Surface Hardness6H
Surface treatmentAnti glare
Luminousness≥85%
Touch controller ICEETI 80
Available touch driversWindows, Linux, Android, Mac, etc
Touch bondingOptical bonding
Touch optionalResistive touch, IR touch optional
Power Supply
Working voltageDC 9~36V
Power consumption15W
Power adapterAC 100 ~ 240V input and DC +12V@3.33A MAX output, 40W
Camera
Pixel1200W
Power supplyUSB
Enclosure
MaterialAluminium alloy bezel+ Zinc Plating cold rolled steel rear housing
FinishFront bezel: Sandblasting+Hard Anodizing,
UV-protection and Anti-discoloration treatment
Rear housing: powder coated
ColorBlack
MountingVESA mount 100*100mm
IP ratingFull IP65
Cooling systemPassive - Fanless
DesignOpen frame design(3mm bezel design optional)
Operating Environment
Temperature RangeOperating: -20 °C ~ 70°C (-4°F ~158°F)
Storage: -30 °C~80°C (-22°F ~176°F)
Relative humidityUp to 100% at all relevant temperatures, non-condensing
VibrationGB/T 2423.10-2019
ShockGB2423.5
EMCClass B
Packing Details
Net weightNet weight 2kg (4.41 lb) Gross weight 2.7kg 5.95 lb)
Product Dimension300×216×50mm
Packing info1pcs/ctn 34×30×10.5cm (13.38×11.81×4.13 in ) 3kg (6.61 lb)
5pcs/ctn 53×35×33cm (20.86×13.77×12.99 in ) 16kg (35.27 lb)
AccessoriesPower plug, power supply
Other
Warranty1 year warranty
CertificatesCE, FCC, RoHS



Applications


Restaurant

Self-service kiosk

Gas station

Payment terminal machine

Vehicle

Bus stop
