Industrial LCD Screen Monitor With Sandblasting Oxidation Process High Resolution 1920*1080
  • Name
  • Name
  • Name
  • Name
  • Name

Industrial LCD Screen Monitor With Sandblasting Oxidation Process High Resolution 1920*1080

Brand Name: Sihovision
Model Number: SL238
MOQ: 1 piece
Price: Negotiation
Payment Terms: T/T, Paypal, L/C, D/A, D/P, Western Union, MoneyGram,
Detail Information
Product Description
Detail Information
Place of Origin:
Shenzhen, China
Certification:
CE, FCC, RoHS
Product Name:
Touch Monitor
Panel Size:
23.8 Inch
Resolution:
1920*1080
Aspect Ratio:
16:9
Contrast Ratio:
1000:1
Luminance:
300cd/m2
Highlight:

1920*1080 LCD Screen Monitor

,

Industrial LCD Screen Monitor

,

Sandblasting Oxidation Process LCD Screen Monitor

Product Description

Custom Emergency Button Industrial 10-Point Capacitive Touch LCD Screen Monitor With Sandblasting Oxidation Process



Features

1. Aluminum alloy frame with sandblasting oxidation process, anti-UV and anti-discoloration treatment, front IP65 waterproof
2. Industrial-grade LCD screen, full viewing angle
3. 10-point capacitive touch screen, protective layer is 2mm tempered glass (chemically strengthened), hardness reaches 7H
4. Custom emergency button hole
5. Custom side handle
6. Custom keyboard tray
7. Use industrial-grade components, work 24/7


Specification

Model:SL238
LCD panel
Panel size23.8"
Display active area527.04(W)x296.46(H) mm / 20.75x11.672 in
Resolution1920*1080
Aspect ratio16:9
Brightness (cd/m²)300 nits
Contrast ratio1000:1
View angle89°/89°/89°/89° (R/L/U/D)
Support Color16.7M
BacklightWLED, 50K hours
Touch panel
Touchscreen TypeProjected Capacitive Touch (up to 10 points )
Surface Hardness7H
Surface treatmentN/A
Luminousness≥85%
Touch controller ICILITEK5200
Available touch driversWindows, Linux, Android, Mac, etc
Touch bondingAir bonding(Optical bonding optional)
Touch options(5 wires restive touch, IR touch, non touch optional)
External I/O Ports
Video input1×VGA, 1×DVI, 1×HDMI
Audio in/out1×3.5mm Line-out, 1×3.5mm Line-in
Touchscreen interface1×USB
Power connector1×Screwable 12V DC jack, 1× 3-pins Phoenix Terminal 12V DC
Power Supply
Working voltageDC 12V (9-36V DC Optional)
Power consumption22W
Power adapterAC 100 ~ 240V input and DC +12V@5A MAX output, 60W
OSD
Function Keys5 Keys: Power/Menu/Up/Down/Return
Menu FunctionsBrightness, Contrast, Screen Setting, Color Temp, OSD Language, Auto Adjust, Reset etc.
Support languagesEnglish, Français, Español, Português, Deutsch, Italiano, Nederlands, Svenska, Suomi, Polski, čeština, Русский, 한국어,日本語, 繁體中文,简体中文
Enclosure
MaterialAluminium alloy bezel+ Zinc Plating cold rolled steel rear housing
FinishFront bezel: Sandblasting+Hard Anodizing,
UV-protection and Anti-discoloration treatment
Rear housing: powder coated
ColorBlack, Silver, White, other color optional
MountingVESA mount 75*75/100*100mm, Panel mount
IP ratingFront panel IP65
Cooling systemPassive - Fanless
Operating Environment
Temperature RangeOperating: -10 °C ~ 60°C (14°F ~140°F)
Storage: -20 °C ~ 70°C (-4°F ~158°F)
Relative humidityUp to 90% at all relevant temperatures, non-condensing
VibrationGB/T 2423.10-2019
ShockGB2423.5
EMCClass B
Packing Details
WeightNet weight 8.4kg
Product Dimension700*410.8*62.5mm
Packing info1pc/ctn 84*19*58cm 16kg
AccessoriesPower adapter, power cord, USB touch cable, HDMI/ VGA cable,
embedded mounting screws
Other
Warranty1 year warranty
CertificatesCE, FCC, RoHS



Applications


Restaurant

Self-service kiosk

Gas station

Payment terminal machine

Vehicle

Bus stop
