Place of Origin:
CN
Brand Name:
Sihovision
Certification:
CE, FCC, RoHS
Model Number:
R-I16BMK
Features
1. Support Windows 10;
2. Support USB2.0 type A connector;
3. Support Battery Single Charger Docking;
4. Support GPS navigation;
5. Support 1D/2D barcode scanner;
6. Support Finger Identification;
7. Rugged IP65 protection level;
8. Support 5000mAh pluggable battery;
9. Support UART port, RJ45 port and customized port;
10. Support Wrist Strap and back jacket;
Specification
Model:R-I16BMK | |
PC | |
CPU | Intel® Skylake M3-6Y30, 4M Cache, 2.20 GHz Optional: kabylake Core™ m3-7Y30 /8200Y |
GPU | Intel® HD Graphics 515 |
RAM | 4GB, Optional: 8GB |
SSD | 64GB, Optional: 128G |
G_sensor | Gravity acceleration sensor |
WIFI | WIFI 802.11(a/b/g/n/ac) dual frequency 2.4G+5.8G WIFI intel 3165D2WG (3.3v) |
Bluetooth | BT4.2 (BLE) class 1, Transmission distance: 10m |
3G | Optional: FIBOCOM_H350 GSM/GPRS/EDGE Band(MHz):900/1800; WCDMA Band(MHz):900/2100, 1.Asia Pacific,Europe, 2.China Unicom 3G |
4G | EC25-EC LTE FDD: B1/B3/B7/B8/B20/B28A WCDMA: B1/B8 GSM: B3/B8 |
GPS | Capture sensitivity: -160 dBm; Cool Start Time:<50second,Hot start time:<28seconds, frequency: 0.25 Hz ~10 MHz (configurable) |
Camera | Front:2.0MP with chargeing indicator light, Rear: 8.0MP USB Camera |
Speaker | 8Ω/0.8W waterproof BOX speaker*1 |
Mic | Sensitivity:-42db, output impedance 2.2kΩ |
Operation System | windows 10 Home/ Pro/ IOT 64bit |
LCD panel | |
Panel size | 10.1", Optional SLR Sunlight visible film |
Resolution | 1200×1920 |
Aspect ratio | 10:16 |
Brightness (cd/m²) | 330 cd/m2 |
Touch panel | |
Touchscreen Type | 10 points Capacitive, G+G |
Surface Hardness | 7H |
Interface | |
USB | 1*USB 3.0 ,1*Micro USB |
Pogo Pin | 1*12pin Pogo Pin |
Audio Output | 1*3.5mm |
HDMI | HDMI 1.4a Type C*1 |
TF Slot | 1*TF Slot, max: 128G |
SIM | 1*SIM |
Power | 1*DC 12V 4A |
DB9 PORT | 1*(RS232) TTL electrical level |
RJ45 PORT | 1*(10/100 self-adaption) |
Air outlet | 1*( build in small board for customer customized ), TLU1HPO2H0709J-50( tong mao Plug), LU1HR04H0709K(tong mao Plug) |
OTG Cable | USB OTG to MICRO USB cable length: 45mm |
USB Cable | USB to micro 5P L=1.2M 4core aluminum foil shield cable |
Power Supply | |
Power Adaptor | AC100V ~ 240V, 50Hz/60Hz, Output DC 12V/4A |
Battery | Lithium-ion polymer battery, pluggable, dimension: 121.8*92.3*9.5mm, Optional: 2pcs |
Capacity: 7.4V/5000mAh | |
6hrs(default 50% volumn,default200nit,play 1080P HD video) | |
Operating Environment | |
IP grade | IP65 waterproof |
Drop Height | 1.22cm composite wood floors, in operation status |
Operate Temperature | -20 °C to 60 °C |
Store Temperature | -30 °C to 70 °C |
Humidity | Humidity: 95% Non-Condensing |
Packing Details | |
Net weight | 1207g |
Gross weight | 2365g |
Product Dimension | 280*187*22mm |
Packing size | 384*222*90mm |
Other | |
Warranty | 1 year warranty |
Certificate | CE, FCC, RoHS |
Color | Black(Front and Rear Panel: Black, Decorate Board:Black) |
Module extension (Optional) | |
One-dimension barcode | MOTO SE655E100R ,Support Buzzer, Optical Position: 5mil, Scan speed: 50/s, Symbol system:UPC/EAN, Bookland EAN ,UCC Coupon Code,ISSN EAN,Code 128,GS1-128,ISBT 128,Code 39,Trioptic Code 39 ,Code 32,Code 93 ,Code 11 |
Two-dimension barcode | Honeywell N3680 hardcode/ Optical resolution:5mil/ scan speed:50 times /s, Code system:PDF417, MicroPDF417, Data Matrix, Data Matrix Inverse, Maxicode,QR Code, MicroQR, QR Inverse,Aztec,Aztec Inverses,Han Xin,Han Xin Inverse |
Optional Accessories | |
Accessories | Docking Charger, Hand-strap, Vehicle Mount, Leather Cover, Back-strap, Shoulder-strap, Carry handle, 5V3A Car Charge, Removable Battery |
