Place of Origin:
CN
Brand Name:
Sihovision
Certification:
CE, FCC, RoHS
Model Number:
R-I11SGH
Features
1. support windows 10 system;
2. support standard USB2.0 port;
3. support docking charging docking extension;
4. support NXP NFC(13.56M);
5. support GPS navigation;
6. support 1D barcode scanner/2D barcode scanner;
7. rugged IP65 grade;
8. support strap.
Specification
| Model:R-I11SGH | |
| PC | |
| CPU | Intel Cherrytrail Z8350, 1.44Ghz-1.92GHz |
| GPU | Intel® HD Graphics |
| RAM | 2GB, Optional 4G |
| SSD | 32GB, Optional 64G/128G |
| G_sensor | G_sensor |
| WIFI | WIFI 802.11(a/b/g/n/ac) dual frequency 2.4G+5.8G WIFI intel 3165D2WG |
| Bluetooth | BT4.2 (BLE) class 1, Transmission distance: 10m |
| 3G | Optional: IC:H350_A30 frequency:WCDMA(900/2100MHz) GSM(900/1800MHz), HSDPA 7.2Mbps, HSUPA 5.76 Mbps |
| 4G | Optional: EC25-E: LTE FDD: B1/B3/B5/B7/B8/B20 LTE TDD: B38/B40/B41 WCDMA: B1/B5/B8 GSM: B3/B8 |
| GPS | Optional: U-blox NEO-7, support : GPS; Capture sensitivity: -160 dBm; Cool Start Time: <50 seconds, Hot start time: <28 seconds, frequency: 0.25 Hz~10 MHz |
| NFC | Optional: NXP NFC 13.56MHz support ISO/IEC 下14443A/14443B/15693/18092/mifare protocol, identification distance: 2-4cm |
| Camera | front 2.0MP with indicator light, rear 5.0MP |
| Speaker | Built-in 8Ω/0.8W waterproof speaker*1 |
| Mic | Sensitivity: -42db, output impedance 2.2kΩ |
| Operation System | windows 10 Pro 32bit, windows 10 Home/Iot 32bit/64bit |
| LCD panel | |
| Panel size | 10.1" |
| Resolution | 800*1280 IPS |
| Aspect ratio | 16:10 |
| Brightness (cd/m²) | 450 cd/m2 |
| Touch panel | |
| Touchscreen Type | multiple points capacity TP(5 points at Max), G+G |
| Surface Hardness | 6H |
| Interface | |
| USB | 1*USB2.0*1 (Host)micr usb |
| Type C | 1*Type C |
| Audio Output | 1*3.5mm |
| HDMI | 1*HDMI 1.4a mini |
| TF Slot | 1*TF Slot, max: 128G |
| SIM | 1*SIM |
| Power | 1*DC 5V 3A, 3.5mm Power Connector, Optional (With overvoltage protection, maximum protective voltage is DC24V) |
| pogo pin | Optional: 1*12pin |
| OTG cable | USB OTG turn MICRO USB cable length 45mm |
| USB cable | USB turn micro 5P L=1.2M, 4 wires with aluminium foil and shielding |
| Power Supply | |
| Power Adaptor | AC100V ~ 240V, 50Hz/60Hz, Output DC 5V/3A |
| Battery | Built-in Li-polymer battery |
| Capacity: 3.7V/8000mAh | |
| nearly 8 hours ( 50% volume sounds, 200 lumens brightness, 1080P HD video display by default ) | |
| Operating Environment | |
| IP grade | IP65 waterproof |
| Drop Height | 1.22cm composite wood floors, in operation status |
| Operate Temperature | -10 °C to 50 °C |
| Store Temperature | -20 °C to 60 °C |
| Humidity | Humidity: 95% Non-Condensing |
| Packing Details | |
| Net weight | 1018g |
| Gross weight | 1867g |
| Product Dimension | 275.5*187.5*22mm |
| Packing size | 384*222*64mm |
| Other | |
| Warranty | 1 year warranty |
| Certificate | CE, FCC, RoHS |
| Color | black (rear housing and front housing) |
| Module extension (Optional) | |
| One-dimension barcode | MOTO SE655E100R/Optical resolution: 5mil/scan speed:50 times/s serial port, Code system: UPC/EAN, Bookland EAN ,UCC Coupon Code,ISSN EAN,Code 128,GS1-128,ISBT 128,Code 39,Trioptic Code 39 ,Code 32,Code 93 ,Code 11 |
| Two-dimension barcode | Honeywell N3680 hardcode/ Optical resolution:5mil/ scan speed:50 times /s, Code system:PDF417, MicroPDF417, Data Matrix, Data Matrix Inverse, Maxicode,QR Code, MicroQR, QR Inverse,Aztec,Aztec Inverses,Han Xin,Han Xin Inverse |
| Optional Accessories | |
| Accessories | Docking Charger, Hand-strap, Vehicle Mount, Carry handle, 5V3A Car Charge |
