Place of Origin:
CN
Brand Name:
Sihovision
Certification:
CE, FCC, RoHS
Model Number:
R-Q11HM
Functions
• Support for Android 9.0 system.
• Integrated 3G/4G all network communication, WiFi, Bluetooth and other communication modes.
• 8000mAh battery, 9 hours of machine endurance.
• IP65 high protection level, in accordance with MIL-STD-810G.
• Support GPS, GLONASS, more accurate positioning.
• Support 13 million pixel auto focus camera, easy to collect images and video information.
• Support 1D/2D, NFC and other functional modules for free selection.
Specification
| Model:R-Q11HM | |
| PC | |
| CPU | Qualcomm(OCTA Core), 2.0GHz |
| OS | Android 9.0 |
| RAM | 4GB LPDDR3 |
| ROM | 64GB |
| Network connections | |
| WIFI | 2.4G+5G dual frequency, WIFI 802.11(a/b/g/n/ac) |
| Bluetooth | BT4.1 (BLE) |
| 3G/4G | LTE FDD: B1/B3/B5/B7/B8/B20 |
| LTE TDD: B38/B40/B41 | |
| WCDMA: B1/B2/B5/B8 | |
| GSM: 850/900/1800/1900MHz | |
| Basic parameters | |
| Dimension | 275.5*187.5 x 22mm |
| Weight | device unit 970g |
| Device Color | black |
| LCD | 10.1inch IPS 16:10, 800*1280 |
| Touch Panel | 10 points Capacitive, G+G |
| Camera | Front 5.0MP Rear 13.0MP |
| I/O | USB 3.0 x 1, Type C x 1, |
| SIM Card x 1, TF Card x 1, | |
| HDMI 1.4a x 1, | |
| 12pins Pogo Pin x 1, | |
| Φ3.5mm standard earphone jack x 1, | |
| Φ3.5mm DC jack x 1 | |
| Power | AC100V ~ 240V, 50Hz/60Hz output DC 5V/3A |
| GPS | Support GPS, glonass |
| Battery (Built-in) | |
| Capacity | 3.7V/8000mAh |
| Type | Built-in Li-polymer battery |
| Endurance | 9hrs(50% volume sounds, 50% brightness,1080P HD video display by default) |
| Reliability | |
| Operate Temperature | -10 °C ~ 50 °C |
| Store Temperature | -20 °C ~ 60 °C |
| Humidity | 95% Non-Condensing |
| IP Grade | IP65 |
| Optional modules | |
| NFC | Support ISO/IEC 14443A protocol, Card reading distance: 3-5cm |
| 1D | MOTO SE655E100R, Optical Position: 5mil, Scan speed: 50 times/s |
| 2D | Honeywell N3680, Optical Position: 5mil, Scan speed: 50 times/s |
