Sunlight Readable 1000nits Total 1.6kgs 15.6 Inch Open Frame Monitor

Place of Origin China(Mainland)
Brand Name SHINHO
Certification CE, FCC, RoHS
Model Number SL156O
Minimum Order Quantity 1 piece
Price Negotiable
Payment Terms T/T, Western Union, MoneyGram, Paypal
Product Details
Product Name 15.6 Inch Open Frame Monitor Color Black Or Silver
Material Aluminum Alloy Resolution 1920*1080
Brightness 1000nits, Sun-readable IP Grade Front Panel IP65 Waterproof
Weight 1.6kgs Warranty 12months
High Light

open frame led monitor

,

industrial open frame monitor

Leave a Message
Product Description

                      Sunlight Readable 1000nits Total 1.6kgs 15.6 Inch Open Frame Monitor





Features



1. 15.6'' widescreen LCD panel, high resolution, 1920*1080, wide viewing angle, high nits, true color.
2. 1000 nits, sunlight readable.
3. Wide voltage: 12-18V
4. Interfaces: VGA+HDMI+DVI.
5. High performance mainboard, 7x24 continuous operation.
6. Support wall mounting, embedded mounting, desk stand mouting etc.
7. Light weight for the monitor, only 1.6KG, suitable for assembling in portable equipment.



Specification



Model:SL156 O
LCD panel
Panel size 15.6"
Resolution 1920*1080
Aspect ratio 16:9
Support Color 16.7M colors
Brightness (cd/m²) 1000 nits, sunlight readable
Contrast ratio 1000:1
View angle 80°/80°/80°/80° (R/L/U/D)
Signal Ports
VGA 1x VGA
DVI 1x DVI
HDMI 1x HDMI
Audio in/out Optional
OSD
OSD control Brightness, contrast ratio, auto adjustment, H/V position, language select, etc.
Support languages English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese, etc.
Support OS Windows XP, Windows /7/8/10, Linux, Mac OS X, Android, ect.
Power Supply
External Power Supply AC 100 - 240V, 50-60Hz
Working voltage DC 12V-18V
Power consumption ≤31W
Enclosure
Material Aluminum alloy
Color Black, Silver
VESA mounting 100x100mm
Operating Environment
Temperature Range Operating: -10 to 60°C, storage: -20 to 80°C
Relative humidity Operating: 10% to 80%, storage: 5% to 90%
Packing Details
Net weight 1.6 kg
Gross weight 2.35 kg
Product Dimension 43.56*24.59*3.35 cm
Packing size 52*46*18 cm
Accessories HDMI cable, power cord, open frame kits
Other
Mounting Embedded mounting screws
Wall mounting brackets (optional)
Desk stand holder (optional)
Warranty 1 year warranty
Certificates CE, FCC, RoHS



Pictures



Sunlight Readable 1000nits Total 1.6kgs 15.6 Inch Open Frame Monitor 0

Sunlight Readable 1000nits Total 1.6kgs 15.6 Inch Open Frame Monitor 1



Drawing



Sunlight Readable 1000nits Total 1.6kgs 15.6 Inch Open Frame Monitor 2



Application



Motion control system



Ticket machine



Voting machine



Control Cabinet



Smart Lockers parcel locker



Face recognition system



Remote authentication



Access control attendance



Intelligent photo album classification



Self-service medical ticketing machine



Automatic medical film taking machine
