Open Frame Industrial Lcd Monitor 12 Inch 1000 Nit 1024*768 With Touch Screen

Place of Origin Shenzhen,China
Brand Name Sihovision
Certification CE,FCC, RoHS
Model Number SL12
Minimum Order Quantity 1 Piece
Price Negotiable
Payment Terms L/C, T/T, Western Union, Paypal, MoneyGram

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name 12 Inch Open Frame Monitor Products Status Stock
Resolution 1024*768 Screen Size 12"
Interface VGA, HDMI, DVI Brightness 1000+ Nits
Touchscreen Type Project Capacitive Touch (10 Points ) IP Grade Front Panel IP65 Waterproof
Viewing Angle 80°/80°/80°/80° (R/L/U/D) Material Aluminum Alloy Frame
Power Supply DC 12V(AC 100-240V 50/60Hz) Widescreen Yes
Panel Type TFT Color Black
Application Embedded/desktop/wall Mount Warranty 1 Years
High Light

sunlight readable display

,

high brightness display

Leave a Message
Product Description

12 inch open frame 1000 nit high brightness monitor with touch screen





Features:



1. Front bezel aluminum alloy brushed metal craft,seamless design, front IP65 waterproof and dustproof .
2. Industrial LCD panel, wide viewing angle, high nits, true color.
3. Adopt multi-points PCAP touch panel , high sensitive and fast-response.
4. High performance mainboard, 7x24 continuous operation.
5. Support wall mounting,embedded mounting,desk stand mouting etc.
6.1000 nits,sunlight readable,ideal for embedded in outdoor kiosk.
7.with light sensor, auto adjust brightness.



Specification



Model:SL12
LCD panel
Panel size 12"
Resolution 1024*768
Aspect ratio 4:3
Support Color 16.7M colors
Brightness (cd/m²) 1000nits,sunlight readable
Contrast ratio 1000:1
View angle 80°/80°/80°/80° (R/L/U/D)
Touch panel
Touchscreen Type Project Capacitive Touch (10 points )
Surface Hardness 3H
Luminousness 90%
Touch Interface USB (RS232 optional)
Touch response time 2ms
Working Life >50 million times
Touch options (4 or 5 wires restive touch, IR touch optional)
Signal Ports
VGA 1×VGA
DVI 1×DVI
HDMI 1×HDMI
Audio in/out optional
OSD
OSD control Brightness, contrast ratio, auto adjustment, H/V position, language select etc.
Support languages English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese etc.
Support OS Windows XP , Windows /7/8/10 , Linux, Mac OS X, Android ect.
Power Supply
External Power Supply AC 100 - 240V , 50-60Hz
Working voltage DC 12V
Power consumption ≤35W
Enclosure
Material aluminium alloy bezel+High strength cold rolled steel back case
Color Black, white, Silver , color can be customized
VESA mounting 100×100mm
IP grade Front panel IP65 waterproof
Operating Environment
Temperature Range operating: -10 to 60°C, storage :-20 to 80°C
Relative humidity operating: 10% to 80% , storage :5% to 90%
Packing Details
Net weight 3kg
Gross weight 4kg
Product Dimension 31×21.85×3.85cm
Packing size 40×33×16cm
Accessories Power adapter, USB touch cable,HDMI cable, open frame kits
Other
Mounting open frame
wall mounting brackets (optional)
desk stand holder (optional)
Warranty 1 year warranty
Certificates CE, FCC, RoHS











Package

Open Frame Industrial Lcd Monitor 12 Inch 1000 Nit 1024*768 With Touch Screen 0



Certifications

Open Frame Industrial Lcd Monitor 12 Inch 1000 Nit 1024*768 With Touch Screen 1



OEM & ODM



Open Frame Industrial Lcd Monitor 12 Inch 1000 Nit 1024*768 With Touch Screen 2



About Shinho Electronic
Open Frame Industrial Lcd Monitor 12 Inch 1000 Nit 1024*768 With Touch Screen 3


Application

Open Frame Industrial Lcd Monitor 12 Inch 1000 Nit 1024*768 With Touch Screen 4




Application
Smart City
Intelligent Education
Public Transportation
Commercial Terminals
Industrial automation area
